G30N04D3 - N-Channel Enhancement Mode Power MOSFET

📥 Download Datasheet

G30N04D3 Datasheet Preview — Preview of G30N04D3 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	G30N04D3
Manufacturer	GOFORD
File Size	727.50 KB
Description	N-Channel Enhancement Mode Power MOSFET
Datasheet	G30N04D3-GOFORD.pdf

G30N04D3 Product details

Description

The G30N04D3 uses advanced trench technology to provide excellent RDS(ON) , low gate charge.It can be used in a wide variety of applications.General

Features

l VDS l ID (at VGS = 10V) l RDS(ON) (at VGS = 10V) l RDS(ON) (at VGS = 4.5V) l 100% Avalanche Tested l RoHS Compliant 40V 30A < 9mΩ < 12mΩ Schematic diagram pin assignment.
