Datasheet Details
- Part number
- 2SD1899
- Manufacturer
- Inchange Semiconductor
- File Size
- 216.70 KB
- Datasheet
- 2SD1899-InchangeSemiconductor.pdf
- Description
- Silicon NPN Power Transistor
2SD1899 Description
isc Silicon NPN Power Transistor .
Low collector saturation voltage.
100% avalanche tested.
Minimum Lot-to-Lot variations for robust device
performance and reliable operati.
2SD1899 Applications
* High transition frequency applications
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
VALUE
UNIT
VCBO
Collector-Base Voltage
60
V
VCEO
Collector-Emitter Voltage
60
V
VEBO
Emitter-Base Voltage
7
V
IC
Collector Current-Continuous
PC
Collector Power Dissipation
3
A
1.0
