3DD15B Datasheet, Transistor, Inchange Semiconductor

PDF File Details

Part number:

3DD15B

Manufacturer:

Inchange Semiconductor

File Size:

206.22kb

Download:

📄 Datasheet

Description:

Silicon npn power transistor.

Collector-Emitter Breakdown Voltage- : V(BR)CEO= 100V(Min.)

DC Current Gain- : hFE= 30~250(Min.)@IC= 2A

Co

3DD15B Application

• Applications
• Designed for B&W TV horizontal output , regulated power supply and power amplifier applications. ABSOLUTE MAXIMUM RATINGS(Ta=
