TPCC8106, Silicon P-Channel MOSFET

MOSFETs Silicon P-Channel MOS (U-MOS) TPCC8106 1.Applications * Motor Drivers * DC-DC Converters * Switching Voltage Regulat.

datasheet Preview Page 1 from Datasheet4u.com

TPCC8106-ToshibaSemiconductor.pdf

TPCC8106 Datasheet Preview — Preview of TPCC8106 PDF

Datasheet Details

Part number:

TPCC8106

Manufacturer:

Toshiba ↗ Semiconductor

File Size:

289.35 KB

Description:

Silicon P-Channel MOSFET

Features

* (1) AEC-Q101 qualified (2) Small, thin package (3) Low drain-source on-resistance: RDS(ON) = 9.5 mΩ (typ. ) (VGS = -10 V) (4) Low leakage current: IDSS = -10 µA (max) (VDS = -40 V) (5) Enhancement mode: Vth = -2.0 to -3.0 V (VDS = -10 V, ID = -1.0 mA) 3. Packaging and Internal Circuit TPCC8106 TSON

Applications

* Motor Drivers
* DC-DC Converters
