EDI7F433512V

512Kx32 FLASH

EDI7F433512V Features

* 512Kx32, 2x512Kx32 and 4x512Kx32 Densities Based on AMDs - AM29LV004T Flash Device Fast Read Access Time - 80ns 3V Only Reprogramming Flexible, Sector Architecture One 16Kbyte, two 8Kbyte, one 32Kbyte and seven 64Kbyte sectors Any combination of sectors can be erased Supports full chip erase Embedde

EDI7F433512V General Description

The EDI7F33512, EDI7F233512 and EDI7F433512 are organized as 512Kx32 and 2x512Kx32 and 4x512Kx32 respectively. The modules are based on AMD's AM29LV004T - 512Kx8 Flash Device in TSOP packages which are mounted on an FR4 substrate. The modules offer access times between 80 and 120ns allowing for oper.

EDI7F433512V Datasheet (124.53 KB)

Preview of EDI7F433512V PDF

Datasheet Details

Part number:

EDI7F433512V

Manufacturer:

White Electronic Designs

File Size:

124.53 KB

Description:

512kx32 flash.
