ZL30410 - Multi-service Line Card PLL

Product Overview

Zarlink Semiconductor

Datasheet Details

Part number	ZL30410
Manufacturer	Zarlink Semiconductor
File Size	426.50 KB
Description	Multi-service Line Card PLL
Datasheet	ZL30410 Datasheet
Additional preview pages of the ZL30410 datasheet.

Product details

Description

The ZL30410 is a Multi-service Line Card Phase-Locked Loop designed to generate multiple clocks for SONET, SDH and PDH equipment including timing for ST-BUS and GCI interfaces.

Features

Generates clocks for OC-3, STM-1, DS3, E3, DS2, DS1, E1, 19.44 MHz and ST-BUS Meets jitter generation requirements for STM-1, OC-3, DS3, E3, J2 (DS2), E1 and DS1 interfaces Compatible with GR-253-CORE SONET stratum 3 and G.813 SEC timing compliant clocks Provides “hit-less” reference switching Detects frequency of both reference clocks and synchronizes to any combination of 8 kHz, 1.544 MHz, 2.048 MHz and 19.44 MHz reference frequencies Continuou.
